Please find Figure 2-1 and Table 2-1 below with the Integra-X package contents.
Figure 2-1 Integra-X package contents
Table 2-1 the Integra-X package content
Products and accessories
Qty
1. D11XS***** Integra-X, 11GHz
1
2. XSPR_2148 RJ45 CAT5 connector 4P
1
3. D0ALK003 Locking key for Integra-X
1
4. XSPR_184 2 pin RIA pluggable terminal block
1
Parts attached to Integra product
5. Diplexer flange, Frequency specific
1
6. MEBG_2893 O-ring AS-568-140
1
7. D0KBS001.003 Integra-X tensioner
4
8. D0KBS001.004 Socket Head screw M6x16
4
9. D0KBSL01.006 Integra-X fixator, ABS
4
10. D0APC001 Port cap
3
11. D0APCS01 Service cork assembly
1
12. D0ACGL01 Cable gland
1
