I/O Wiring Examples
Input Connection Example
Potentiometer
1-10k Ohm Pot. Recommended
(2 Watt minimum)
P108 [Speed Reference] = 2 “0-10V Input”
Analog Input
0 to +10V, 100k ohm impedance
4-20 mA, 100 ohm impedance
Voltage
P108 [Speed Reference] = 2 “0-10V Input”
Current
P108 [Speed Reference] = 3 “4-20mA
Input”
