T-Max® Manager/Plus and T-Max®3A/F/I User’s Guide Page 41
12.4 Figure D - J99 and J100 Jumper Settings
1 2 3 1 2 3 1 2 3
Jumper Positions for J99 and J100
12.5 Figure E - Connecting The T-Max® Sentry™
Load Carrying Line
from Tanning Bed.
Run the load carrying line from the tanning
bed through the center of the T-Max®
Sentry™ then back to the bed. If you do not
know where this wire on our tanning bed is,
contact the tanning bed manufacturer. For
beds that pull less than 10 AMPS, see Figure
Wires screw into Sensor input E, Section 12.6.
on T-Max®3A/F/I (see Figure C, Section 12.3)
The T-Max® Sentry™
Jumper On Pins 1 and 2 Jumper on Pins 2 and 3 Jumper Off
