T-Max® Manager/Plus and T-Max®3A/F/I User’s Guide Page 3
Options:
T-Max® Enclosure™
Attaches to the T-Max®3A/F/I to hang on the wall or set on a desk.
T-Max® Speaker (Optional):
Connects to T-Max®3A/F/I to provide higher alarm indications.
T-Max® Sentry (Optional; 1 required for each T-Max®3A/F/I):
Indicates if bed is not operating properly.
T-Max® Slave Kit (Optional) :
Required for additional slave T-Max® Mgr/Plus.
T-Max® Monitor (Optional):
Provides 64 dual-color lights to show the status of all beds in your salon.
T-Max® Monitor/Plus (Optional):
Provides 16 displays showing bed times and statuses.
ADNET-Repeater (Optional):
Connects in the middle of the daisy chain amplify the communications signal.
1.2 Specifications
T-Max® Mgr/Plus:
Power Supply
IN - 120VAC
OUT – 9VDC @ 1A
Current Draw
800mA
Dimensions
10” x 5.25” x 2”
Communication
T-Max® Mgr/Plus - PC RS-232C, 9600 Baud, 8Bit, 1 Stop Bit, No Parity
T-Max®3A/F/I and T-Max® 3A/I/Master:
Power Supply
IN - 120VAC
OUT - 12V AC @ 1A
Current Draw
800mA
Dimensions:
Cover Plate:
9 W” x 5.175 H”;
T-Max®3A/F/I PCB:
2.87 x H 2.3”D x 7.5” W”
Enclosure: 5.24”H x 9” W x 2.75” D x 2” D
Relay (T-Max® 3A/F/I only):
220VAC @ 5A; SPST Form A
Display:
T-Max® Mgr/Plus: 64 dual color lights showing bed status.
1, 16x2 LCD display shows individual bedtime and status.
T-Max®3A/F/I: 1, 2 digit LED display showing bedtime and status.
T-Max3A/I/Master: 1 dual colored LED display.
Maximum Units:
128 T-Max®3A/F/I’s controlling 128 beds.
8 T-Max® Mgr/Plus’s can be used to control up to 128 beds.
1 Computer can be connected to each T-Max® Mgr/Plus.
