12.10 Figure J - Multiple Configurations
Optional Computer
Up to
Optional Computer 128 Beds!
Connect Multiple T-Max® Mgr/Plus’s, Computers, and up to 128 Beds!
T-Max® Mgr/Plus
(M )
T-Max® Mgr/Plus (Slave 1)
T-Max® Mgr/Plus (Slave 7)
Room 128
Room 64
Room 2
T-Max®
Slave Kits
Up to 8 T-Max®
Mgr/Plus can be
connected in a single
salon.
Room 1
T-Max® 3A/I/Mstr
ADNET-
Repeater™
Legend: Modular Cables w/RJ-22 Connectors
Modular Cables w/RJ-45 Connectors
Audio input for in-
room automated
messages
