Salon Systems T-Max Manager - 12.8 Figure H - T-Max Manager;Plus Rear View

T-Max® Manager/Plus and T-Max®3A/F/I User’s Guide Page 43
12.8 Figure H - Rear View Of T-Max® Manager/Plus
T-Max® Mgr/Plus PCB
Jumper On Jumper Off Jumper Off
Jumper Positions for J1 and J2 Jumpers
DB9F RS232 Port
LCD PCB
Z80
Battery
Ribbon Cable
75176
RJ-22 Port
Power
Jumper JP1 and JP2:
On is Master, Off if
Slave
