102 • Service Mode Programming Sam4s ER-260EJ/256EJ OP Manual v1.20
progress of the download. At the ECR, the display will flash slowly while the update
is taking place.
10. When complete, the message Completed displays on the PC. Click OK and the
Download program will close. At the ECR, the display will change to a blue color
indicating the update is complete. Turn the power switch to the OFF.
Program Area Update
1. Connect the Serial Cable from ECR to PC.
2. At the register, move to the SERVICE MODE.
3. Turn the power switch to the OFF position.
4. Press the upper right key and the lower right key. A rapid beep-beep-beep sound will
be heard. Release the upper right key and the lower right key.
5. Press the ↑ key and the ↓ key to select menu and press the CASH key to confirm.
Select the 1.SERIAL1 menu.
6. At the PC, execute the program “Download.exe”. The Download dialog box
displays.
7. Select the appropriate com port connection at your PC at the PORT# option buttons.
8. Click find the folder where the update files are located and select binary file.
9. Select Program code + Font in the Select One option buttons.
10. Press OK Button. The download takes about 3 minutes. At the PC, the scroll bar
will track the progress of the download. At the ECR, the display will flash (Current
program is being erased), after a few seconds, the display will continue to flash, but
at a slower rate. This continues for about 3 minutes while the new program is being
loaded.
11. When complete, the message Completed displays at the PC. Click OK and the
Download program will close. At the ECR, when the load is complete, a rapid beep-
beep-beep will be heard, and the display will flash rapidly. Turn the power switch to
OFF, the program update is complete.
12. Disconnect the PC cable.
13. Perform a memory all clear on the ECR. The ECR is now ready to program or to
load a previously saved end-user program.
