Required ECR Program Settings
Define Port (Serial Port Options)
You must define one of the three serial communication ports for the DataCap device you will be using
for EMV.
Port Settings
1. Move the key to the S lock position to display the Service Mode menu.
2. From the Service Mode menu press CHARGE1 and the CHARGE2 keys to scroll up and
down until “DEFINE PORT” is selected (or press 5 to directly to the ‘DEFINE PORT’.)
3. Press CASH. The DEFINE PORT menu displays:
DEFINE PORT
1.PORT 1
4. Use CHARGE1 and the CHARGE2 keys to scroll up and down through the Define Port
menu. Or, enter the digit (1-3) corresponding to the serial port you wish to program. (Select
or press 4 and CASH to set the USB port. Select or press 5 and CASH to print Port1, Port2
and Port3 settings.)
PORT 1
1.BAUD RATE
[19200]
5. Use the CHARGE1 and the CHARGE2 keys to scroll up and down through the eleven
serial port options. Make settings or changes as needed.
6. Press the CLEAR key to finalize and return to the DEFINE PORT screen.
Serial port Settings Screen Program Notes
# Option Description
1 BAUD RATE
Select 19200 for EMV enabled DataCap devices
2 PARITY
Select NONE
3 DATA BITS
Select 8
4 STOP BITS
Select 1
5 DEVICE FUNCTION
Select DATATRAN
