9 Exploded Views and Parts List
9-4 SAM4S ER-380M/F SERIES
9-1-2-(b) Case Upper Assembly (ER-380F)
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
B JK94-01125A PRA ETC-CASE-UPPER: ER-380F,STD 1 Y
B-1 JK72-20063A
PMO-WINDOW DISPLAY:ER-380,PC,BLK
1 Y
B-2 JK72-20064A
PMO-COVER MODE S/W:ER-380F,HIPS,IVR,V0
1 Y
ER-380F
B-3 6002-000319 SCREW-TAPPING: PH,+,2,M3,L8,ZPC(YEL) 2 Y
B-4 JK70-10004A IPR-BRKT MODE_S/W: SBHG-1,T1 1 Y
B-5 6002-000319 SCREW-TAPPING: PH,+,2,M3,L8,ZPC(YEL) 2 Y
B-6 6002-000172 SCREW-TAPPING: PH,+,2S,M4,L15 1 Y
B-7 JK96-00956A ELA ETC-MODEKEY ASSY: ER-380 1 Y
B-8 JK72-40209B PMO-WINDOW TURRET: PC 1 Y
B-9 JK92-01231A PBA SUB-TURRET: ER-380 1 Y
B-10 JK72-00015A PMO-TURRET BODY: HIPS(V0) 1 Y
B-11 6001-000367 SCREW-MACHINE: FH,+,M4,L10 1 Y
B-12 JK70-40305A ICT-SHAFT MOLDING: SUM 24L,FISCAL 1 Y
B-13 JK72-00012B PMO-CASE UPPER: ER-380,FISCAL 1 Y
B-14 JK70-10407A
IPR-BRKT WINDOW_PCB:ER-550,SECC,T1.2
1 Y
B-15 6002-000175
SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL)
4 Y
B-16 JK92-01242A PBA SUB-380,DISPLAY: FUTABA,10G 1 Y
B-17 6002-000175
SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL)
4 Y
B-18
JK39-40002A CBF HARNESS:ER-220N,-,UL1061,400MM,BLK/R
1 Y
