9 Exploded Views and Parts List
9-6 SAM4S ER-380M/F SERIES
9-1 Main Set
9-1-2 Parts List
9-1-2-(d) Case Lower Assembly
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
E-14 6006-000199
SCREW-ASS'Y TAPT:WT,BH,+,M4,L8,ZPC(YEL)
1 Y
E-15 6002-000174
SCREW-TAPPING:PWH,+,2,M3,L10,ZPC(YEL)
2 Y
E-16 JK92-01280A PBA SUB-I/F:ER-380/M,232*2 1 Y
E-17 6003-000259
SCREW-TAPTITE:BH,+,B,M3,L8,ZPC(YEL),SWRC
3 Y
E-18 JK72-00013C PMO-CASE LOWER,S2:ER-380,HIPS 1 Y
E-19 6002-000171
SCREW-TAPPING: PH,+,2S,M4,L10,ZPC(YEL)
1 Y
E-20 JK70-10002A IPR-BRKT CASING: ER-380,SBHG-1,T1.6,- 1 Y
E-21 JK70-20018A IPR-BRKT TRANS:ER-380,SECC T1.6 1 Y
JK39-10002A CBF-POWER CORD: AUSTRALIA 1 Y
JK39-10003A CBF-POWER CORD: USA 1 Y
JK39-10008A CBF-POWER CORD: UK 1 Y
E-22
JK39-10501A CBF-POWER CORD: EUROPE 1 Y
E-23 JK96-10035A ELA-MOTOR ASS'Y: ER-380 1 Y
E-24 JK72-40206A PMO-HOLDER MOTOR: HIPS(V0) 1 Y
E-25 JK73-30200A RCT-MOTOR: URETANE,BLK 1 Y
JK96-10036A ELA ETC-MOTOR ASS'Y 1 Y
3101-001071 MOTOR-DC: 3270rpm,16g.cm,9V,130mA 1 N
E-26
JK39-40604A HARNESS-SPOOL;ER-380,2P,400mm,NO CORE
1 N
E-27 JK92-01227C PBA SUB-POWER SW:ER-380 1 Y
E-28 6001-000665 SCREW-MACHINE:PWH,+,M3,L4,ZPC(YEL) 2 Y
