10 PCB Layout and Parts List
10-2 SAM4S ER-380M/F SERIES
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Part-No Description / Specification Q’TY Design Location
Serviceabl
e
Remark
s
- JK92-01260A PBA MAIN-BOARD:ER-380M,FISCAL 1
- 0202-000216 SOLDER-BAR:S63S-B20,S63S,350X34,SN63/PB3 1
- 0202-001025 SOLDER-WIRE FLUX:KS-611,-,-,-,spray 1
- 0204-000469 THINNER:#4662,-,0.795,- 1
- 0201-000008 ADHESIVE-HM:#3748,WHT,6500CPS,V2 1 X1,X2,L5,
- 0402-000168 DIODE-RECTIFIER:1N5822,40V,3A,DO-201AD,T 1 D3
- 0402-000290 DIODE-BRIDGE:KBU6B,100V,6A,-,BK 1 BD1
- 0403-000141 DIODE-ZENER:1N4735A,6.2V,5%,1W,DO-41,TP 1 ZD1
- 0501-000294 TR-SMALL SIGNAL:KSA708-Y,PNP,800mW,TO-92 1 Q6
- 0501-000294 TR-SMALL SIGNAL:KSA708-Y,PNP,800mW,TO-92 1 Q14
- 0501-000294 TR-SMALL SIGNAL:KSA708-Y,PNP,800mW,TO-92 1 Q15
- 0502-000234 TR-POWER:KSA1010Y,PNP,40W,TO-220,TP,100 1 Q11
- 0502-000288 TR-POWER:KSD288,NPN,25W,TO-220,-,120-24 1 Q1
- 1102-000161 IC-EPROM:27C040,512Kx8BIT,DIP,32P,600MI 1 U19
- JC68-10564A LABEL(P)-PROTECTOR:SLB-3108H,ART,-,100(S 1 U19
- 1106-000245 IC-SRAM:684000,512Kx8BIT,DIP,32P,600MI 1 U15
- 1203-000442 IC-POSI.FIXED REG.:7812,TO-220,3P,-,PLAS 1 U22
- 1209-001089 IC-DETECTOR:M51953B,SIP,5P,-,PLASTIC,18V 1 U8
- 2001-000027 R-CARBON:100OHM,5%,1/4W,AA,TP,2.4X6.4MM 1 R10
- 2001-001291 R-CARBON: 1OHM,5%,1/2W,AA,TP,3.5X9.5MM 1 R35
- 2003-000502 R-METAL OXIDE(S):150ohm,5%,2W,AA,TP,4x12 1 R26
- 2005-001001 R-WIRE WOUND:0.1ohm,5%,1W,AA,TP,3.3x9mm 1 R20
- 2005-001001 R-WIRE WOUND:0.1ohm,5%,1W,AA,TP,3.3x9mm 1 R21
- 2005-001001 R-WIRE WOUND:0.1ohm,5%,1W,AA,TP,3.3x9mm 1 R22
- 2301-000010 C-FILM,PEF:100nF,5%,100V,TP,11.5x12.5mm, 1 C1
- 2401-000032 C-AL:100uF,20%,50V,GP,TP,8x12,5mm 1 C27
- 2401-000042 C-AL:100uF,20%,16V,GP,TP,6.3x7,5 1 C48,C50,C83,C92
- 2401-000603 C-AL:1uF,20%,50V,GP,TP,5x11,5 1 C77
- 2401-001312 C-AL:4700uF,20%,50V,GP,BK,22x40,10 1 C5
- 2401-001363 C-AL:470uF,20%,16V,GP,TP,10x12.5,5 1 C34
- 2401-001429 C-AL:470uF,20%,50V,GP,TP,13x20,5 1 C7
- 2401-002620 C-AL:2200uF,20%,50V,GP,BK 1 C4
- 2801-003263 CRYSTAL-UNIT:14.7456MHz,50ppm,28-ABR,30p 1 X1
- 2801-003376 CRYSTAL-UNIT:0.032768MHz,20ppm,28-AAY,12 1 X2
- 3002-001027 BUZZER-PIEZO:85dB,1.5V,24mA,2.048KHz,BK 1 AU1
- 3301-000344 CORE-FERRITE BEAD:AA,-,3.5x0.6x6.5mm,-,- 1 L6
- 3601-000261 FUSE-CARTRIDGE:250V,3.15A,TIME-LAG,GLASS 1 FU1
- 3602-000001 FUSE-CLIP:-,-,30mohm 2 FU1
- 3701-000240 CONNECTOR-DSUB:9P,2R,FEMALE,STRAIGHT,AUF 1 CN2
- 3701-000240 CONNECTOR-DSUB:9P,2R,FEMALE,STRAIGHT,AUF 1 CN4
- 3704-000255 SOCKET-IC:32P,DIP,SN,2.54mm 1 U19
- 3704-000255 SOCKET-IC:32P,DIP,SN,2.54mm 1 U15
