Fig. 5 ⋅ Diagram of connections
WARNING
Always disconnect the power supply lines prior to plugging/removing the plug
connectors.
If this is ignored, the glass fuse Type T63 mA/250 V (order no. 8834-0298) con-
tained on the power board in the device may be required to be exchanged.
5
E
D
4
C
3
C
+
+
I
U
V
mA
PE
PE
PE
HE
HE
+ -
+ -
Pt 100
Ni 100
_
_
L
N
1
C
BE
2
B
1
A
F
5
7
H
+
Y
Y1
Y2
_
t
A
PE
PELN
+
_
24 V DC
+
_
+
_
x-Recorder
4(0) to 20 mA
Y1 and Y2 can defined by the user for use
as limit values or motor drive
9
