1 Preparations
Components
Be sure to use only the components and parts provided with your bracket for installation.
Fixing the main unit to the bracket:
The appearance of the main unit may differ from the image shown (The assembly and installation of the
plastic pieces and screws are the same as the images shown).
1 Remove the 4 screws from the back of the main unit.
2 Combine the plastic pieces with the screws (B).
z After hanging the main unit on the bracket, check from the left and right sides that all the
plastic pieces are firmly in place.
z Exercise caution when installing or adjusting the angle of the main unit to prevent the fingers
from being caught.
z Ensure that the bracket is firmly fixed to the wall to prevent the main unit from falling off and
causing injuries.
Bracket x 1 Hinge x 2 (left
and right)
Plastic piece
x 4
Screw A x 11 Screw B x 4 Anchor x 11
