Product Specifications
Samsung Electronics 2-23
Indoor Unit(cont.)
QBig Duct
Model ND200HHXE6 ND220HHXE6 ND280HHXE6
Power Supply ø/V/Hz 1/220-240/50 1/220-240/50 1/220-240/50
Mode*
1)
HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 20.0 22.4 28.0
Btu/h 68,200 76,400 95,500
Heating*
3)
kW 22.4 25.0 31.5
Btu/h 76,400 85,300 107,500
Condensate (with High fan speed) Liters/h
Power
Input W 400 530 790
Running Current A 3.3 3.8 5.9
Sound Level Sound Pressure (High/Low)*
4)
dB(A) 46 / 43 47 / 44 48 / 45
Fan
Type - Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model - DL-13875SSOB DL-13875SSOB DL-13875SSOB
Type - BLDC BLDC BLDC
Output W
Airflow Rate
Cooling (High) m
3
/min 52 58 72
Heating (High) m
3
/min 52 58 72
External Static Pressure Standard(Min.~Max) mmH2O 15(5-25) 15(5-25) 15(5-28)
Refrigerant
Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 9.52 9.52 9.52
Gas (Flare) ø, mm 19.05 19.05 22.2
Drain ø, mm VP25(OD32, ID25) VP25(OD32, ID25) VP25(OD32, ID25)
Weight
Net Weight kg 93 95 95
Shipping Weight kg 103 105 105
Dimensions
Net Dimensions (W x H x D) mm 1,240x470x1,040 1,240x470x1,040 1,240x470x1,040
Shipping Dimensions (W x H x D) mm 1,507x558x1,155 1,507x558x1,155 1,507x558x1,155
Functions
Auto Restart - O O O
Auto Swing - X X X
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - X X X
Standard
Accessories
Installation Manual - O O O
Operation Manual - O O O
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - X X X
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00
Duct Receiver
Kits
Receiver
- MRK-A00 MRK-A00 MRK-A00
Receiver Wire
- MRW-10A MRW-10A MRW-10A
Wired Remote
Controller
Simplified - MWR-WH02 MWR-WH02 MWR-WH02
Standard - MWR-WE10 MWR-WE10 MWR-WE10
Premium -
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
Drain Pump MDP-N047SNC1 MDP-N047SNC1 MDP-N047SNC1
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
