106
Inspection and trial operation
Measure to take when E503 error occurs
Perform Trial Operation (cooling/heating)
- See the instructions on Key operation modes.
Perform Auto Trial Operation again
Ye s
Ye s
Ye s
Ye s
Ye s
Take corrective measures.
No.
Is the ball valve on the outdoor unit
opened?
Take corrective measures.
No.
Has the correct amount of additional refrigerant
been injected into the indoor unit and liquid line?
Take corrective measures.
No.
Are the 4-way valve, Main EEV and
pressure sensors operating properly?
Take corrective measures.
No.
Is the operation cycle normal?

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung DVM S Series and is the answer not in the manual?

Samsung DVM S Series Specifications

General IconGeneral
RefrigerantR410A
Operating Temperature Range (Cooling)-5°C to 48°C
Piping Length (Total)1000m
Inverter TechnologyYes
TypeVRF System
Compressor TypeInverter Scroll Compressor
Energy EfficiencyHigh Efficiency
ControlCentralized Control, Individual Control
Indoor Unit OptionsCassette, Duct, Wall Mount, Ceiling
