76

Electrical wiring work

Installing the Solution device

f When the number of indoor units installed with the outdoor unit is 16 or less

F1 F2 OF1 OF2 R1 R2

F1

Terminal block with indoor

unit

F2

OF1

Terminal block with

outdoor unit sub module

OF2

R1

Terminal block with

solution device

R2
