23
ENGLISH
Accessories
Accessories
f You must keep following accessories until the installation is nished.
f Hand over the installation manual to the customer after nishing the installation.
Installation manual (1)
Optional accessories
f Following optional accessories are needed for connecting pipes between the indoor and outdoor units.
Classication Model Name Specication
Y-Joint
MXJ-YA1509M 15.0 kW and below
MXJ-YA2512M 15.1 kW ~ 40.0 kW
MXJ-YA2812M 40.1 kW ~ 45.0 kW
MXJ-YA2815M 45.1 kW ~ 70.3 kW
MXJ-YA3419M 70.4 kW ~ 98.4 kW
MXJ-YA4119M 98.5 kW ~ 135.2 kW
MXJ-YA4422M Over 135.2 kW
Y-Joint (Only H/R)
MXJ-YA1500M 22.4 kW and below
MXJ-YA2500M 22.5 kW ~ 70.3 kW
MXJ-YA3100M 70.4 kW ~ 135.2 kW
MXJ-YA3800M Over 135.2 kW
Distribution header
MXJ-HA2512M 45.0 kW and below (for 4 rooms)
MXJ-HA3115M 70.3 kW and below (for 8 rooms)
MXJ-HA3819M 70.4 kW ~ 135.2 kW (for 8 rooms)
Y-Joint
- Outdoor unit
MXJ-TA3419M 135.2 kW and below
MXJ-TA4122M Over 135.2 kW
Y-Joint (Only H/R)
- Outdoor unit
MXJ-TA3100M 135.2 kW and below
MXJ-TA3800M Over 135.2 kW
❇ If you use an indoor unit with no internal EEV(Electric Expansion Valve), you will need an EEV kit.
❇ Only use the genuine accessories listed in above table and do not use imitated accessories.

Samsung DVM S Series Specifications

General

Refrigerant	R410A
Operating Temperature Range (Cooling)	-5°C to 48°C
Piping Length (Total)	1000m
Inverter Technology	Yes
Type	VRF System
Compressor Type	Inverter Scroll Compressor
Energy Efficiency	High Efficiency
Control	Centralized Control, Individual Control
Indoor Unit Options	Cassette, Duct, Wall Mount, Ceiling
