Setting the Pipe Addresses Manually
You can use the wired or wireless remote control or the S-NET Pro 2 to set the pipe addresses for each indoor unit.
Setting by using the wired or wireless remote control (For how to operate the remote control
buttons, see the remote control user manual.)
1. Turn on both the indoor unit and the remote control.
2. Enter the “Option setting mode” on the remote control.
3. Set the address of each MCU port that is connected to an indoor unit by referring to the following table. (You can also set
the address of each indoor unit.)
Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
Value
0
A: Address setting
mode
0: The address of the
indoor unit will not
be set.
1: The address of
the indoor unit will
be set.
0 to 9: Hundreds
digit of the indoor
unit address
0 to 9: Tens digit
of the indoor unit
address
0 to 9: Units digit
of the indoor unit
address
Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
Value
10
0: The RMC address
will not be set.
1: The RMC address
will be set.
0
0 to F: RMC group
channel
0 to F: RMC group
address
Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
Value
20
0: The MCU address
will not be set.
1: The MCU address
will be set.
0 to 1: Tens digit of
the MCU address
0 to 9: Units digit of
the MCU address
A to F: MCU port
address
Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
Value
300000
Examples> If the indoor unit whose address is not yet set is connected to port A on the MCU 1, set 0A0000-100000-
20101A-300000.
If the indoor unit whose address is set to 9 is connected to port B on the MCU 2, set 0A1009-100000-20102B-300000.
Setting by using S-NET Pro 2
f Set the pipe addresses by using Add-on > Change address on S-NET Pro 2. (For more information, see the S-NET Pro 2
Help.)
