Selecting solderless ring terminal
f Select a solderless ring terminal for a power cable according to the nominal dimensions for cable.
f Apply insulation coating to the connection part of the solderless ring terminal and the power cable.
Silver solder
Nominal dimensions for cable (mm
2
) 4/6 10 16 25 35 50 70
Nominal dimensions for screw (mm) 4888888888
B
Standard dimension (mm) 9.51515161216.516222224
Allowance (mm) ±0.2 ±0.2 ±0.2 ±0.3 ±0.3 ±0.3 ±0.4
D
Standard dimension (mm) 5.6 7.1 9 11.5 13.3 13.5 17.5
Allowance (mm)
+0.3
-0.2
+0.3
-0.2
+0.3
-0.2
+0.5
-0.2
+0.5
-0.2
+0.5
-0.2
+0.5
-0.4
d1
Standard dimension (mm) 3.4 4.5 5.8 7.7 9.4 11.4 13.3
Allowance (mm) ±0.2 ±0.2 ±0.2 ±0.2 ±0.2 ±0.3 ±0.4
E Min. (mm) 6 7.9 9.5 11 12.5 17.5 18.5
F Min. (mm) 5 9 9 13 15 13 13 13 14 20
L Max. (mm) 2028.53033 34 38435051
d2
Standard dimension (mm) 4.3 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4 8.4
Allowance (mm)
+ 0.2
0
+ 0.4
0
+ 0.4
0
+ 0.4
0
+ 0.4
0
+ 0.4
0
+ 0.4
0
+ 0.4
0
t Min. (mm) 0.9 1.15 1.45 1.7 1.8 1.8 2.0

Samsung DVM S Series Specifications

General

Refrigerant	R410A
Operating Temperature Range (Cooling)	-5°C to 48°C
Piping Length (Total)	1000m
Inverter Technology	Yes
Type	VRF System
Compressor Type	Inverter Scroll Compressor
Energy Efficiency	High Efficiency
Control	Centralized Control, Individual Control
Indoor Unit Options	Cassette, Duct, Wall Mount, Ceiling
