Classication
Model name of
indoor unit
Number of units
Unit amount of
refrigerant (kg/EA)
Amount of
additional
refrigerant (kg)
Total amount
of additional
refrigerant (kg)
①②①×② ∑(①×②)
Indoor unit (ⓑ)
4way cassette
(AM071FN4DEH✴)
50.452.25
ⓑ 4.66
4way cassette
(AM112FN4DEH✴)
20.571.14
Neo Forte
(AM028FNTDEH✴)
10.270.27
MCU 2 0.5 1
- Total amount of refrigerant (ⓐ+ⓑ) = 11.965+4.66 = 16.625 (kg)
Temper grade and minimum thickness of the refrigerant pipe
Outer diameter (mm) Minimum thickness (mm) Temper grade
Ø 6.35 0.70
Annealed
Ø 9.52 0.70
Ø 12.70 0.80
Ø 15.88 1.00
Ø 19.05 0.90
Drawn
Ø 22.22 0.90
Ø 25.40 1.00
Ø 28.58 1.10
Ø 31.75 1.10
Ø 34.92 1.20
Ø 38.10 1.35
Ø 41.28 1.43
Ø 44.45 1.60
Ø 50.80 2.00
Ø 53.98 2.10
• For pipes larger than Ø 19.05, drawn type (C1220T-1/2H or C1220T-H) type copper pipe must be used. If a
annealed type (C1220T-O) copper pipe is used, pipe may break due to its low pressure resistance and cause
personal injury.
CAUTION

Samsung DVM S Series Specifications

General

Refrigerant	R410A
Operating Temperature Range (Cooling)	-5°C to 48°C
Piping Length (Total)	1000m
Inverter Technology	Yes
Type	VRF System
Compressor Type	Inverter Scroll Compressor
Energy Efficiency	High Efficiency
Control	Centralized Control, Individual Control
Indoor Unit Options	Cassette, Duct, Wall Mount, Ceiling
