POWER BUTTON (
Turns the receiver on/off.
INPUT SELECT CONTROL
Used to select a source.
FM ; DVD ; AUX ; TV ; USB
AUDIO ASSIGN CONTROL
Toggles to select an input mode for the selected source.
STOP/PLAY BUTTON
Play, pause or stop playing the music in the USB connection.
3D SOUND BUTTON
Press to apply 3D Sound effect.
DISPLAY
Displays the speaker/audio input status, listening mode, etc.
DSP/EQ BUTTON
Select the desired DSP/EQ audio mode.
DIMMER BUTTON
Adjust the brightness of Display.
TUNING MODE BUTTON
Used to select the Manual or Preset mode for FM radio.
MEMORY BUTTON
Used to set a preset radio frequency.
TUNING CONTROL
Used to change the radio frequency.
MASTER VOLUME CONTROL
Adjusts the volume level.
USB
PORT
Connect the USB storage device to play a multimedia le of video, photo, and
music.
AUX IN JACKS
Auxiliary AV input terminals used to connect a camcorder, portable DVD player or
gaming device.
