Screen Setup
SHR-2160/2162/2080/2082 USER’S MANUAL
5-17
● It is a window to set Brightness/Contrast/Color for the camera image of each channel.
Put the cursor on the channel that you want to adjust and set Brightness/Contrast/Color.
Once selected, the channel appears in the right PIP area. Use the
or button to adjust
the value from 0 to 100.
● If you select CH >, all the channels will have the same values as the selected channel.
● “Default value” resets the current channel to the basic value of 50.
● In the case of the 2080/2082, 8-channel information comes up.
SHR-2160/2162/2080/2082-E-1 10/19/07 9:36 AM Page 5-17
