English
5-18
3
Monitoring
●
Event Monitoring
It is possible to set to Off / 3sec / 5sec / 10sec / 20sec / 30sec / Continuous.
① Off : Event Monitoring does not operate to turn to the screen where an event occurs.
➁ 3sec / 5sec / 10sec / 20sec / 30sec : Sets the duration time of screen in the Auto
Sequence mode.
➂ Continuous : The Event Monitoring screen remains alive until you press the “Alarm”
button in the front to cancel the screen manually.
●
OSG Display
① Date :
The date is displayed on the screen when it is On, and not displayed when it is Off.
➁ Time :
The time is displayed on the screen when it is On, and not displayed when it is Off
.
➂ Cam name : The Cam name is displayed on the screen when it is on, and not displayed
when it is off.
➃ Status :
Audio/Ptz is displayed on the screen when it is on, and not displayed when it is off.
●
Spot Out Channel
Spot Out channel is used to let one of two monitors monitor a channel, focusing on it.
Spot Out channel supplies two functions, continuous monitoring of only one channel and
Auto Sequence to display all the channels one by one.
① Auto Sequence setup ranges from Ch1 to Ch16.
➁ In the Auto Sequence mode, Spot Out channels are displayed in turn.
➂ Duration time for Auto Sequence is as same as set for Camera setup.
●
Spot Out Event Monitor
Sets if event monitoring will be executed for Spot Out channels.
① Off : The event monitoring dose not operate in the Spot Out channel.
➁ 3sec / 5sec / 10sec / 20sec / 30sec : Sets the duration time of screen in the Auto
Sequence mode.
➂ Continuous : Once scrolled down, the screen remains displayed until you delete “Alarm”
LED in the front manually.
SHR-2160/2162/2080/2082-E-1 10/19/07 9:36 AM Page 5-18
