English
● Image output
Pressing both the mode button and zoom button on the front left side the same time for five
seconds switches the VGA status to Composite status and Composite status to VGA status
then reboots.
① Composite : Makes the output come out through the “Composite / S-Video OUT” port.
➁ VGA : Makes the output come out through the “VGA Out” port.
When changing the output from Composite to VGA or from VGA to
Composite, the system reboots automatically.
● Play channel location
Designates the one channel location to play in play 9 split mode.
Lower right-hand corner : Sets the location at the lower right-hand corner.
Center : Sets the location in the center.
● Multi-channel change
You can set changes for a split screen.
You can set it to 3, 5, 10, 20, or 30 seconds.
SHR-2160/2162/2080/2082 USER’S MANUAL
5-19
Caution
Caution
[Video Out]
When setting the Composite Output, VGA output does not come out.
When setting the VGA Output, Composite Output does not come out.
If you press the MODE button and the ZOOM butteon for 5 seconds in the front, the system
will change from VGA to COMPOSITE or from COMPOSITE to VGA and reboot.
VGA output : 640 X 480 (60Hz)
