Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN91-13767A ASSY LCM-SDC;CY-YJ065FLLV1V,BN95-01956A 1 SNA
0.2 PANEL BN95-01956A PRODUCT LCD-SDC;CY-YJ065FLLV1V,JS9500,Ba 1 SA
..3 6001-002912 SCREW-MACHINE;CH,+,M3,L3,ZPC(BLK),SWRCH1 24 SA
..3 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 24 SA
..3 6001-003058 SCREW-MACHINE;CH,+,M3,L6,ZPC(WHT),SWRCH1 4 SNA
..3 BN02-00352K TAPE PET;JS9000,PET,0.05T,15,35,BLK 2 SNA
..3 P001A BN44-00819A DC VSS-LED TV PD BD;L65SM9NC_FSM,L65SM9N 1 SA
..3 BN68-05595A LABEL-STICKER;Art Paper 100G,T0.2,80mmX2 1 SNA
..3 BN90-06435A ASSY MISC-BLU;N9 65 1 SNA
...4 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 24 SA
...4 BN02-00152U TAPE PET-SHEET FIXING;JS9500,PET,T 0.05, 2 SNA
...4 BN61-11345A HOLDER-MIDDLE(U);Y15 Q9000 65",PC+G/F10% 1 SNA
...4 BN61-11346A HOLDER-MIDDLE(D);Y15 Q9000 65",PC+G/F10% 1 SNA
...4 BN61-11347A HOLDER-MIDDLE(LR);Y15 Q9000 65",PC+G/F10 2 SNA
...4 BN61-11630A LGP-DIFFUSESR PLATE;65inch Curved, Diffu 1 SNA
...4 BN63-13404A SHEET-DBEF;DBEF D2 400,PC,0.4,1429.66,80 1 SNA
...4 BN63-13409A SHEET-COMPLEX;UTA20B-10P,PET,0.33,1429.6 1 SNA
...4 BN63-13439A SHEET-QD;UTQ10B-9B,PET,0.34,1434.69,808. 1 SNA
...4 BN96-35255A ASSY FRAME P-MOLD MIDDLE U;N9 65,PC+ABS+ 1 SNA
....5 BN60-01120V SPACER-PANEL(UD_B);LED N9 65inch,SI RUBB 1 SNA
....5 BN60-01120W SPACER-PANEL(UD_C);LED N9 65inch,SI RUBB 1 SNA
....5 BN61-11358A FRAME-MOLD MIDDLE(U);Y15 Q9000 65",PC+GF 1 SNA
...4 BN96-35256A ASSY FRAME P-MOLD MIDDLE D;N9 65,PC+ABS+ 1 SNA
....5 BN60-01120U SPACER-PANEL(UD_A);LED N9 65inch,SI RUBB 2 SNA
....5 BN60-01120X SPACER-PANEL(UD_D);LED N9 65inch,SI RUBB 1 SNA
....5 BN60-01120Y SPACER-PANEL(UD_E);LED N9 65inch,SI RUBB 1 SNA
....5 BN61-11359A FRAME-MOLD MIDDLE(D);Y15 Q9000 65",PC+GF 1 SNA
...4 BN96-35261A ASSY FRAME P-MOLD MIDDLE LR;N9 65,PC+ABS 2 SNA
....5 BN60-01120T SPACER-PANEL(LR_A);LED N9 78inch,SI RUBB 4 SNA
....5 BN60-01128A SPACER-PANEL(LR_A);LED N9 65inch,SI RUBB 2 SNA
....5 BN61-11360A FRAME-MOLD MIDDLE(LR);Y15 Q9000 65",PC+G 2 SNA
...4 BN96-35264A ASSY MISC P-CHASSIS BOTTOM;Y15 JS9500 65 1 SNA
....5 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 14 SA
....5 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 12 SNA
....5 BN60-00162A SPACER-FOAM;FOAM,50000L,BLK,0.35T,20W 1 SNA
....5 BN60-00554A SPACER-SOURCE;SNB 40/46/55,SI RUBBER,10, 2 SNA
....5 BN61-08936C BRACKET-WALL, BOTTOM, BLK;JS9500,EGI-SEC 4 SNA
....5 BN61-10711A HOLDER-RIVET;Y14 VDTV H8000 U9000 55 65, 14 SNA
....5 AB285 BN61-11372A BRACKET-REAR;N9 65",EGI-SECC,1.2 2 SNA
....5 BN61-11448A SUPPORT-PLATE;LED N9 65inch,ABS+PC,V0,WH 30 SNA
....5 BN61-11450A HOLDER-REAR L;LED N9 65inch,PC+GF10%,BLK 1 SNA
....5 BN61-11451A HOLDER-REAR R;LED N9 65inch,PC+GF10%,BLK 1 SNA
....5 BN61-11466A HOLDER-SOURCE PCB;LED N9,ABS,BLACK,HB,HF 8 SNA
....5 BN61-11764A SUPPORT-PLATE;LED N9 65inch,ABS+PC,V0,NH 10 SNA
....5 BN62-00694A INSULATION-DRIVE BOARD 65;Y15 N9000 65,P 1 SNA
....5 BN62-00696A INSULATION-PD BOARD 65;Y15 N9000 65,PC,0 1 SNA
....5 BN62-00700A INSULATION-LED CNT HOLE;Y15 N9000 88,PC, 3 SNA
ANNEX-4
ANNEX. Exploded View & Part List
