Samsung UN JS9500F Series User Manual

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN65JS9500FXZA (TS01)
1 R001A BN90-06575A ASSY COVER REAR;JS9.5K,65",NORTH AMERICA 1 SNA
0.2 SCREW 6001-002996 SCREW-MACHINE;FH,+,M3.0,L5.0,ZPC(BLK),SW 10 SA
0.2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 11 SA
0.2 R001A BN96-35470A ASSY COVER P-REAR;JQ9500 65",PC+ABS GF15 1 SA
..3 0203-001085 TAPE-DOUBLE FACE;#706BH,T0.64,W12,BLK 6 SNA
..3 BN61-04692A BOSS-PRIMER;#94,SHEET,clear,35cps 0 SNA
..3 BN63-00044A GASKET-EMI;1503FP,Conductive Fabric,19MM 14 SNA
..3 CCM1 BN63-02183H SHEET-COVER;Rhcm,PE,T0.05,1300mm,200M,HB 2 SNA
..3 R001 BN63-13163A COVER-REAR;LED N9 65inch,PC+ABS+GF15%,V1 1 SNA
..3 BN63-13178A COVER-MASK;Q9 65",PCM,0.5,HAIRLINE 1 SNA
..3 BN63-13815J SHEET-COVER REAR UL;JS9500 65",PET,0.048 1 SNA
..3 BN63-13815K SHEET-COVER REAR UR;JS9500 65",PET,0.048 1 SNA
..3 BN63-13815P SHEET-COVER REAR L;JS9500 65,PET,0.048,W 1 SNA
..3 BN63-13815Q SHEET-COVER REAR R;JS9500 65,PET,0.048,W 1 SNA
..3 BN68-07079A LABEL-LICENSE;JS9000,PET,T0.125,81,73,BL 1 SNA
1 BN90-06584A ASSY W/I;JS9.5K,65" 1 SNA
0.2 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC 1 SNA
0.2 BN81-09501M A/S PART SET-MECH W/I;UJ9Y,U65JY* 1 SNA
1 S001A BN90-06834C ASSY STAND;JS9.5K,65",NORTH AMERICA 1 SNA
0.2 SB04A BN96-35472B ASSY STAND P-BASE;JS9500 65",USA,ALDC,HA 1 SA
..3 6902-002462 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W100,L50 2 SNA
..3 6902-002469 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W160,L30 1 SNA
..3 BN63-13175B COVER-STAND BASE;LEDJS9.5K.65,AL,HAIRLIN 1 SNA
..3 BN67-00398L RUBBER-FOOT;RUBBER,SILICONE,15.5*8,2,GRA 6 SNA
0.2 SG01A BN96-35479B ASSY GUIDE P-STAND;JS9500 65",USA,ABS,HB 1 SA
..3 SCREW 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 8 SA
..3 SCREW 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 SA
..3 6902-002059 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L40 1 SNA
..3 BN61-11627A BRACKET-STAND, NECK;Q8000 65",HGI 1 SNA
..3 BN61-11629A BRACKET-STAND, NECK-LINK;JS9000 65",EGI- 1 SNA
..3 AH089 BN61-11739B HOLDER-CABLE;JS9500,ABS,palting. W/W 1 SNA
..3 BN61-12070A BRACKET-STAND,NECK-FRONT;JQ9000 65",HGI, 1 SNA
..3 AS080 BN63-07229C SHEET-COVER;rose70",SI,T0.052,W70mm,100M 0 SNA
..3 BN63-13166A COVER-STAND NECK SUB;Q9 65",PC+ABS+GF15% 1 SNA
..3 BN63-13339D COVER-STAND, NECK-FRONT;LEDJS9.5K,65,ABS 1 SNA
..3 BN63-13399E COVER-STAND, NECK-REAR;LEDJS9.5K,65,ABS, 1 SNA
..3 BN68-05603A LABEL-E,PASS;ALL MODEL,ART PAPER 90G,60, 1 SNA
..3 BN96-27704A ASSY ACCESSORY-SCREW;6003-001208,4EA,ALL 1 SNA
...4 SCREW 6003-001208 SCREW-TAPTYPE;BH,+,S,M4,L12,ZPC(BLK),SWR 4 SA
...4 BN69-08203L BAG SCREW;LDPE,-,0.05,70,90,TRP,-,-,6003 1 SNA
..3 BN96-36028A ASSY ACCESSORY-SCREW;JS9.5K,6001-001961( 1 SNA
...4 6001-001961 SCREW-MACHINE;FH,+,M4,L12,ZPC(BLK),SWRCH 4 SA
...4 6902-000341 BAG PE;LDPE,T0.05,L90,W70,TRP,,,PE MARK 1 SNA
