5-4
5. Wiring Diagram
3
CN902_DB (ARM JTAG)
1 B3.3V_PW 5 SERDES_TCK
2 SERDES_TRST_L 6 SERDES_TDO
3 SERDES_TDI 7 MRST
4 SERDES_TMS 8 DGND
4
CN203 (VBY1)
1 IDENT_JACKPACK 27 UHDVIDEO_F-_VBY1
2 FRC_SDA_I2C 28 DGND
3 AGING_EN 29 UHDVIDEO_G+_VBY1
4 FRC_SCL_I2C 30 UHDVIDEO_G-_VBY1
5 BT_SYNC 31 DGND
6 TCON_SDA_OUT_I2C 32 UHDVIDEO_H+_VBY1
7 MAIN_I2C_SW_OUT 33 UHDVIDEO_H-_VBY1
8 TCON_SCL_OUT_I2C 34 DGND
9 DGND 35 VX1_LOCKN1
10 DGND 36 VX1_HTPDN
11 UHDVIDEO_A+_VBY1 37 DGND
12 UHDVIDEO_A-_VBY1 38 DGND
13 DGND 39 DGND
14 UHDVIDEO_B+_VBY1 40 DGND
15 UHDVIDEO_B-_VBY1 41 N.C
16 DGND 42 PANEL_13V_PW
17 UHDVIDEO_C+_VBY1 43 PANEL_13V_PW
18 UHDVIDEO_C-_VBY1 44 PANEL_13V_PW
19 DGND 45 PANEL_13V_PW
20 UHDVIDEO_D+_VBY1 46 PANEL_13V_PW
21 UHDVIDEO_D-_VBY1 47 PANEL_13V_PW
22 DGND 48 PANEL_13V_PW
23 UHDVIDEO_E+_VBY1 49 PANEL_13V_PW
24 UHDVIDEO_E-_VBY1 50 PANEL_13V_PW
25 DGND 51 PANEL_13V_PW
26 UHDVIDEO_F+_VBY1
5
CN201 (SERDES)
1 B3.3V_PW 14 SERDES_RX2-
2 GCLK1_CLK 15 DGND
3 DGND 16 SERDES_RX1+
4 SERDES_TX1+ 17 SERDES_RX1-
5 SERDES_TX1- 18 DGND
6 DGND 19 SERDES_RX5+
7 SERDES_RX4+ 20 SERDES_RX5-
8 SERDES_RX4- 21 A5V_PW
9 DGND 22 TX_MICOM_JACK
10 SERDES_RX3+ 23 RX_MICOM_JACK
11 SERDES_RX3- 24 GCLK0_CLK
12 DGND 25 B13V_JP_PW
13 SERDES_RX2+ 26 B13V_JP_PW
6
CN301 (SPEAKER)
1
TWT_R+_-18V_+18V_
AO
7
TWT_L+_-18V_+18V_
AO
2
TWT_R-_-18V_+18V_
AO
8
TWT_L-_-18V_+18V_
AO
3
MID_R+_-18V_+18V_
AO
9
MID_L+_-18V_+18V_
AO
4
MID_R-_-18V_+18V_
AO
10
MID_L-_-18V_+18V_
AO
5
WF_R+_-18V_+18V_
AO
11
WF_L+_-18V_+18V_
AO
6
WF_R-_-18V_+18V_
AO
12 WF_L-_-18V_+18V_AO
7
CN1102 (IR & FUNCTION & BLU)
1 IR 8 LED_CTRL
2 DGND 9 KEY_INPUT1
3 A3.3V_PW 10 KEY_INPUT2
4 DSCL 11 DGND
5 DSDA 12 N.C
6 A3.3V_PW 13 N.C
7 A3.3V_PW 14 N.C
8
CN1103_DB (SUBMICOM SW DOWNLOAD)
1 DGND 3 SCL_DOWN
2 SDA_DOWN DGND
