5-5
5. Wiring Diagram
9
CN801 (BT/WIFI COMBO)
1 BT_NRESET 9 REF_SYNC_IN
2 POWER_DET 10 DGND
3 WAKE_BT 11 DGND
4 A5V_PW 12 WIFI+_USB
5 BT-_USB 13 WIFI-_USB
6 BT+_USB 14 A5V_PW
7 DGND 15 WAKE_ON_LAN
8 BT_SYNC_BUFF 16 WIFI_NRESET
10
CN202 (LD)
1 DGND 4 LD_SDA_I2C
2 DGND 5 B5V_PW
3 LD_SCL_I2C 6 DGND
11
CN1101_DB (SUMICOM DEBUG)
1 DGND 5 N.C
2 DOUT 6 N.C
3 RIN 7 DGND
4 N.C
