5
CN400_MAIN(FROM MAIN)
1 IN_B12V_PW 18 DGND 35 RX_5+_VBY1
2 IN_B12V_PW 19 RX_0-_VBY1 36 DGND
3 IN_B12V_PW 20 RX_0+_VBY1 37 RX_6-_VBY1
4 IN_B12V_PW 21 DGND 38 RX_6+_VBY1
5 IN_B12V_PW 22 RX_1-_VBY1 39 DGND
6 IN_B12V_PW 23 RX_1+_VBY1 40 RX_7-_VBY1
7 IN_B12V_PW 24 DGND 41 RX_7+_VBY1
8 IN_B12V_PW 25 RX_2-_VBY1 42 DGND
9 IN_B12V_PW 26 RX_2+_VBY1 43 MAIN_CHECK
10 IN_B12V_PW 27 DGND 44 TCON_SCL_I2C
11 N.C 28 RX_3-_VBY1 45 TCON_EN_I2C
12 DGND 29 RX_3+_VBY1 46 TCON_SDA_I2C
13 DGND 30 DGND 47 BT_SYNC
14 DGND 31 RX_4-_VBY1 48 FRC_SCL_I2C
15 DGND 32 RX_4+_VBY1 49 AGING_EN
16 VB1_HTPDN_RX 33 DGND 50 FRC_SDA_I2C
17 VB1_LOCKN_RX 34 RX_5-_VBY1 51 IDENT_JACKPACK
6
CN801_TCON(TO TCON)
1 PANEL_DETECT2 15 N.C 29 DGND
2 TEM_SEL_0 16 N.C 30 TX_11+_VBY1
3 PANEL_RATIO 17 DGND 31 TX_11-_VBY1
4 PATTERN_CHK 18 TX_15+_VBY1 32 DGND
5 LR_SYNC 19 TX_15-_VBY1 33 TX_10+_VBY1
6 N.C 20 DGND 34 TX_10-_VBY1
7 N.C 21 TX_14+_VBY1 35 DGND
8 N.C 22 TX_14-_VBY1 36 TX_9+_VBY1
9 N.C 23 DGND 37 TX_9-_VBY1
10 N.C 24 TX_13+_VBY1 38 DGND
11 N.C 25 TX_13-_VBY1 39 TX_8+_VBY1
12 N.C 26 DGND 40 TX_8-_VBY1
13 N.C 27 TX_12+_VBY1 41 DGND
14 N.C 28 TX_12-_VBY1
