5-22
5. Wiring Diagram
7
CN800_TCON (TO TCON)
1 PANEL_DETECT0 18 TX_5-_VBY1 35 VB1_LOCKN_TX
2 PANEL_DETECT1 19 DGND 36 VB1_HTPDN_TX
3 AGING_EN 20 TX_4+_VBY1 37 DGND
4 PANEL_PMIC_EN 21 TX_4-_VBY1 38 DGND
5 EEPROM_WP 22 DGND 39 DGND
6 TCON_SDA_I2C 23 TX_3+_VBY1 40 DGND
7 TCON_EN_I2C 24 TX_3-_VBY1 41 N.C
8 TCON_SCL_I2C 25 DGND 42 PANEL_12V_PW
9 3D_ENABLE 26 TX_2+_VBY1 43 PANEL_12V_PW
10 DGND 27 TX_2-_VBY1 44 PANEL_12V_PW
11 TX_7+_VBY1 28 DGND 45 PANEL_12V_PW
12 TX_7-_VBY1 29 TX_1+_VBY1 46 PANEL_12V_PW
13 DGND 30 TX_1-_VBY1 47 PANEL_12V_PW
14 TX_6+_VBY1 31 DGND 48 PANEL_12V_PW
15 TX_6-_VBY1 32 TX_0+_VBY1 49 PANEL_12V_PW
16 DGND 33 TX_0-_VBY1 50 PANEL_12V_PW
17 TX_5+_VBY1 34 DGND 51 PANEL_12V_PW
