SAMWONTECH
2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 1 / 2
※ This manual applies to TEMP2300, TEMP2500 and TEMP2700.
※ The model stated the manual content is TEMP2500.
Contents
1. Safety Precautions
1.1 Package checklist …………………………………………………………………………………………… 3
1.2 Dimension & Installation …………………………………………………………………………………·· 5
1.3 Wiring ………………………………………………………………………………………………………… 11
1.4 Display Unit description …………………………………………………………………………………·· 22
1.5 Control Unit LED description ……………………………………………………………………………·· 23
2. SYSTEM SETTING CONFIGURATION
2.1 MAIN MENU Screen ………………………………………………………………………………………·· 24
2.2 SYSTEM PARAMETER setting sequence ………………………………………………………………·· 26
3. INPUT SET
3.1 Sensor Input setting ………………………………………………………………………………………·· 27
3.2 PIECE BIAS setting ………………………………………………………………………………………… 33
4. CONTROL & RETRANSMISSION OUTPUT
4.1 Control Output setting ……………………………………………………………………………………· 35
4.2 Retransmission Output setting …………………………………………………………………………· 37
4.3 Output Terminals displays / settings ……………………………………………………………………·· 41
5. DIGITAL OUTPUT (DO) CONFIGURATION
5.1 DO parameters & RELAY number setting ………………………………………………………………·· 43
5.2 UP, SOAK, DOWN signal operation ………………………………………………………………………· 50
6. COMMUNICATION
6.1 Communication Interface setting …………………………………………………………………………·51
6.2 Communication Configuration …………………………………………………………………………· 52
7. INNER SIGNAL (IS) CONFIGURATION
7.1 Inner Signal setting ………………………………………………………………………………………·· 55
7.2 Inner Signal operation ……………………………………………………………………………………·· 57
8. ON/OFF SIGNAL
8.1 ON/OFF Signal setting …………………………………………………………………………………… 58
8.2 ON/OFF Signal operation ………………………………………………………………………………· 60
To Next Page
