SAMWONTECH
2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 21 / 87
1.3.3.6 TEMP2300 DISPLAY UNIT Communication wiring
1.3.3.7 TEMP2500/2700 DISPLAY UNIT Communication wiring
15 ~ 20 mm
30 ~ 40 mm
