2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 34 / 87
⑤ Compensated Temperature between Input Comp. 4 ~ Input Comp. 5 Section
= Actual Sensor Temperature + (Actual Sensor Temperature – Input Comp. Point 4) X
+ Input Comp. 4 Value
⑥ Compensated Temperature between Input Comp. 5 ~ Input Comp. 6 Section
= Actual Sensor Temperature + (Actual Sensor Temperature – Input Comp. Point 5) X
+ Input Comp. 5 Value
⑦ Compensated Temperature between Input Comp. 6 ~ Input Comp. 7 Section
= Actual Sensor Temperature + (Actual Sensor Temperature – Input Comp. Point 6) X
+ Input Comp. 6 Value
⑧ Compensated Temperature between Input Comp. 7 ~ Input Comp. 8 Section
= Actual Sensor Temperature + (Actual Sensor Temperature – Input Comp. Point 7) X
+ Input Comp. 7 Value
⑨ Compensated Temperature between Input Comp. Point 8 ~ High Limit Section
= Actual Sensor Temperature + Input Comp. 8 Value
(Input Comp. Point 5 – Input Comp. Point 4)
(Input Comp. 5 Value – Input Comp. 4 Value)
(Input Comp. Point 6– Input Comp. Point 5)
(Input Comp. 6 Value – Input Comp. 5 Value)
(Input Comp. Point 7– Input Comp. Point 6)
(Input Comp. 7 Value – Input Comp. 6 Value)
(Input Comp. Point 8– Input Comp. Point 7)
(Input Comp. 8 Value – Input Comp. 7 Value)
