Table 10-3 PID Group Setup Screen Parameter
Parameter Range Unit Default
Proportion #n 0.0(ON/OFF Control) 0.1~1000.0% % 5.0
Integral Time #n 0~6000 SEC ABS 120
Differential Time #n 0~6000 SEC ABS 30
High Limit #n % 100.0
Low Limit #n
0.0~100.0 %
Low Limit #n < High Limit #n
% 0.0
Compensation #n -5.0~105.0 % % 100.0
ON/OFF Control
High Hysteresis #n
EUS(0.0~10.0%) EUS EUS(0.5%)
ON/OFF Control
Low Hysteresis #n
EUS(0.0~10.0%) EUS EUS(0.5%)
* #n : 1 ~ 6
