2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 84 / 87
▶ This screen is displayed when Display Method is set to Picture.
▶ ①, ②, ③ functions are available when Display Set is selected to ‘Picture’.
① Selects the picture on initial screen when power ‘ON’.
② Uploads INIT.BMP file in the SD CARD into internal memory.
③ Displays whether SD CARD stores INIT.BMP file or not.
☞
button is deactivated when there is no INIT.BMP file.
④ Initialize internal memory.
Table 13-1.System Initial Setup Screen-1 Parameter
Parameter Range Unit Default
Language Set ENG, KOR, CHN ABS ENG
Display Method Text, Picture ABS Text
System Password 0 ~ 9999 ABS 0
User Key Unuse, Use ABS Unuse
Information 1
0 ~ 9, A ~ Z, Special Character
(Maximum 24 Characters)
ABS SAMWONTECH CO.,LTD.
Information 2
0 ~ 9, A ~ Z, Special Character
(Maximum 24 Characters)
ABS TEL : 82-32-326-9120
Initial screen
Information
Information 3
0 ~ 9, A ~ Z, Special Character
(Maximum 24 Characters)
ABS HTTP://WWW.SAMWONTECH.COM
Internal memory Total Capacity 28.5MB
①
②
③
[Figure 13-2] System Initial Setup Screen-1/2
④
