CompactFlash Memory Card Product Manual
SanDisk CompactFlash Memory Card Product Manual © 1998 SANDISK CORPORATION 15
2.0 Product Specifications
For all the following specifications, values are
defined at ambient temperature and nominal
supply voltage unless otherwise stated.
2.1 System Environmental
Specifications
Standard SDCFB-XX
Product
Industrial SDCFBI-XX
Product
Temperature Operating:
Non-Operating:
0° C to 60° C
-25° C to 85° C
-40° C to 85° C
-50° C to 100° C
Humidity Operating:
Non-Operating:
8% to 95%, non-condensing
8% to 95%, non-condensing
8% to 95%, non-condensing
8% to 95%, non-condensing
Acoustic Noise: 0 dB 0 dB
Vibration Operating:
Non-Operating:
15 G peak to peak max.
15 G peak to peak max.
15 G peak to peak max.
15 G peak to peak max.
Shock Operating:
Non-Operating:
2,000 G max.
2,000 G max.
2,000 G max.
2,000 G max.
2.2 System Power Requirements
SDCFB-XX
(Standard Version)
SDCFBI-XX
(Industrial Version)
DC Input Voltage (VCC)
100 mV max. ripple (p-p)
3.3V ±5% 5V ± 10% 3.3V ±5% 5V ±5%
+5 V Currents
(maximum Average value)
See Notes 1 to 3.
Sleep:
Reading:
Writing:
Read/Write Peak
200 µA
(Slow - Fast)
32 mA - 45 mA
32 mA - 60 mA
150 mA/50µs
500 µA
(Slow - Fast)
46 mA - 75 mA
46 mA - 90 mA
150 mA/50µs
200 µA
(Slow - Fast)
32 mA - 45 mA
32 mA - 60 mA
150 mA/50µs
500 µA
(Slow - Fast)
46 mA - 75 mA
46 mA - 90 mA
150 mA/50µs
Note 1. All values quoted are typical at ambient temperature and nominal supply voltage unless otherwise stated.
Note 2. Sleep mode currently is specified under the condition that all card inputs are statis CMOS levels and in a
“Not Busy“ operating state.
Note 3. The currents specified show the bounds of programmability of the product.
