4.3.3 Output Drive Type
Note: In the table below, x refers to the characteristics described in section 4.3.4. For example, OT3 refers to
Totempole output with a type 3 output drive characteristic.
Type Output Type Valid Conditions
OTx Totempole Ioh & Iol
OZx Tri-State N-P Channel Ioh & Iol
OPx P-Channel Only Ioh Only
ONx N-Channel Only Iol Only
4.3.4 Output Drive Characteristics
Type Parameter Symbol Conditions MIN TYP MAX Units
1 Output Voltage Voh
Vol
Ioh = -4 mA
Iol = 4 mA
Vcc
-0.8V
Gnd
+0.4V
Volts
2 Output Voltage Voh
Vol
Ioh = -8 mA
Iol = 8 mA
Vcc
-0.8V
Gnd
+0.4V
Volts
3 Output Voltage Voh
Vol
Ioh = -8 mA
Iol = 8 mA
Vcc
-0.8V
Gnd
+0.4V
Volts
X Tri-State
Leakage Current
Ioz Vol = Gnd
Voh = Vcc
-10 10 µA
