CompactFlash Memory Card Product Manual
SanDisk CompactFlash Memory Card Product Manual © 1998 SANDISK CORPORATION 17
Figure 2-1 CompactFlash Memory Card Dimensions
Refer to the following table and to Figure 2-2 for
CompactFlash Memory Card PC Card Adapter
physical specifications and dimensions.
Model SDCF-03 Weight: 33 g (1.16 oz) typical
Length: 85.6 ± 0.20 mm (3.370 ±.008 in)
Width: 54.0 ± 0.10 mm (2.126 ±.004 in)
Thickness: 5.0 mm Max (0.1968 in)
