Attribute
Offset
Data 7 6 5 4 3 2 1 0 Description of
Contents
CIS Function
146h 21h X
0
R
0
P
1
RO
0
A
0
T
1
Power-Down, and Twin Card.
T:Twin Cards Allowed
A:Audio Supported
RO:Read Only Mode
P:Power Down Supported
R:Reserved
X:More Misc Fields Bytes
TPCE_MI
148h 1Bh CISTPL_CE Configuration Entry Tuple Tuple Code
14Ah 06h Link to next tuple is 6
bytes. Also limits size of
this tuple to 8 bytes.
Link to next tuple
14Ch 03h I
0
D
0
Configuration Index
3
AT Fixed Disk Secondary I/O
3.3V configuration
TPCE_INDX
14Eh 01h M
0
MS
0
IR
0
IO
0
T
0
P
1
P:Power info type TPCE_FS
150h 21h R
0
DI
0
PI
1
AI
0
SI
0
HV
0
LV
0
NV
1
PI:Peak Current
NV:Nominal Operation
Supply Voltage
Power Parameters for Vcc
152h B5h X
1
Mantissa
6h = 3.0
Exponent
5h = 1
Nominal Operation Supply
Voltage = 3.0V
Nominal Operation Supply
Voltage
154h 1Eh X
0
1Eh +.30 Nominal Operation Supply
Voltage
Extension Byte
156h 4Dh X
0
Mantissa
9h = 4.5
Exponent
5h = 10
Max Average Current over
10 msec is 45mA
Max Average Current
158h 1Bh CISTPL_CE Configuration Entry Tuple Tuple Code
15Ah 04h Link to next tuple is 4 bytes. Link to next tuple
15Ch 07h I
0
D
0
Configuration Index
7
AT Fixed Disk Secondary I/O
3.3V configuration
TPCE_INDX
15Eh 00h M
0
MS
0
IR
0
IO
0
T
0
P
0
P:Power info type TPCE_FS
160h 028h SanDisk Code Reserved
162h 0D3h SanDisk Code Reserved
164h 014h CISTPL_NO_LINK Prevent Scan of Common
Memory
Tuple Code
166h 000h No Bytes Following Link Length is 0 Bytes Link to next tuple
168h 0FFh End of Tuple Chain End of CIS Tuple Code
