Sanwa cd732 - AC Voltage Measurement (ACV)

ACV
Power outlet
ACV
measurement
5-3 AC voltage measurement (ACV)
ACV
AC 750 V
6.000 V, 60.00 V, 600.0 V, 750 V
Function
Maximum rated input
WARNING
1. Never apply a voltage signal exceeding the maximum rated input value.
2. Do not turn the rotary switch to change the function during measurement.
3. Always keep your fingers behind the finger guards on the test
lead when making a measurement.
Note:
● With the AC 6.000 V range, a few counts of numeric may
remain when the input is 0 (shorted).
● As this instrument employs the mean value method for the
AC detection, measurements become erroneous when the
input waveform is other than a sine wave (the frequency
range is 45 to 500 Hz).
Ranges
– 40 –
