Sanwa cd732 - Diode Test

●
0.556
V
.0 V
Press the SELECT button
to switch to “ ”.
Diode
Anode
Cathode
Forward test
Reverse test
5-7 Diode test ( )
WARNING
Never apply an external voltage or current to the measurement
terminals.
Note:
● The open voltage across the measurement terminals is about
2.7 V.
● If the forward voltage of the diode is equal to or more than
the open voltage, “O.L” is displayed even in the forward test.
– 44 –
