Sanwa cd732 - Current Measurement Introduction; Low Current Measurement (DC;AC µA, mA)

Check that the built-in fuses are not blown.
Function
Maximum rated input
Ranges
1. Never apply voltage to the input terminals.
(Applicable to both sections 5-10-1 and 5-10-2)
2. Be sure to make a series connection via load.
(please see to above drawing)
3. Do not apply an input exceeding the maximum rated current
to the input terminals.
5-10 Current Measurement (μA, mA, A)
5-10-1 DC/AC current (DC/AC µA, DC/AC mA)
Power Power
Load Load
WARNING
〔×〕
Wrong connection
〔○〕
Right connection
CAUTION
600.0 μA, 6000 μA
60.00 mA, 600.0 mA
DC/AC μ A
DC/AC mA
6000 μA
600.0 mA
– 47 –
