Sanwa cd732 - Continuity Check

Extension
cord
Continuity
lamp
Press the SELECT button
to switch to “ ”.
5-8 Circuit continuity check ( )
WARNING
Never apply an external voltage or current to the measurement
terminals.
Note:
● The open voltage across the measurement terminals is about
0.63 V.
● The continuity buzzer beeps and the continuity lamp lights
when the resistance is between 10 and 60 Ω.
Buzzer beep
– 45 –
