Operating the PTZ dome camera
15
b Iris/Tour/Sequence operations
1 Select "IRIS/TOUR/SEQUENCE" using the control
button ({|) and press the ENTER button.
2 To perform tour operations press the control button
({), to stop tour operations press the ENTER
button.
3 To perform sequence operations press the control
button (|), to stop sequence operations press the
ENTER button.
4 Adjust the aperture using the control button (}~).
• The following message is displayed on the screen.
Up/Down key: Tour ON/Sequence ON
Left/Right key: Iris Close/Open
Enter key: Tour/Sequence OFF
b Camera menu settings
1 Select "MENU" using the control button ({|) and
press the ENTER button.
2 Select a menu using the control button ({|) and
select a setting value using the control button (}~).
3 To switch to the next screen or validate a setting
value press the ENTER button.
• The following message is displayed on the screen.
Up/Down key: Cursor Up/Down
Left/Right key: Cursor Left/Right
Enter key: Enter
4
Press the EXIT/STOP button once operation are
complete.
3
If no "PROTOCOL" is set on the PTZ screen, the following
message is displayed on the screen.
"Please set up a camera type in setup menu."
