SYSTEM settings
40
Refer to "Setting the clock (CLOCK SET)". (P9)
Refer to "Setting the clock (CLOCK SET)". (P9)
To be set when devices, such as a system controller or a
SANYO protocol camera, are connected to the RS-485
control terminal.
1
Select "RS485 SET" using the control button ({|)
and press the ENTER button.
The "RS485 SET" screen is displayed.
2
Select the item to be set using the control button
({|) and select a setting value using the control
button (}~).
DATA SPEED: 2400/4800/9600/19200
ADDRESS: 0 - 128
Refer to "Operating the PTZ dome camera". (P14)
Refer to "Setting the language (LANGUAGE)". (P11)
G
Setting the DATE FORMAT
H
Setting the CLOCK SET
I
Setting the RS485 SET
J
Setting the PTZ CONTROL
K
Setting the LANGUAGE
RS485 SET
DATA SPEED 9600
ADDRESS 1
