18
Installation
Projection lens can be moved from side to side and up and down with the motor-driven lens shift function. This
function makes the positioning of images easy on the screen.The amount of lens shift range varies depending
on the lens. The shift ranges shown below apply to the LNS-S03 lens. (See page 28)
Lens Shift Adjustment
When the lens is shifted to top
The display position can be
shifted upward up to 50%
elevation of the display.
When the lens is shifted to bottom
The display position can be
shifted downward up to 50%
low level of the display.
When the lens is shifted to leftmost
The display position can be
shifted to the left in up to
10% width of the display.
When the lens is shifted to rightmost
The display position can be
shifted to the right in up to
10% width of the display.
