Sanyo PLC-HF15000L

94
Configurations of Terminals
ANALOG TERMINAL(Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
CONTROL PORT CONNECTOR (D-sub 9 pin)
DIGITAL (DVI-D) TERMINAL (DVI 24 PIN)
1
9
17
2
10
18
3
11
19
4
12
20
5
13
21
6
14
22
7
15
23
8
16
24
USB PORT(Series B)
2
34
1
1 3 5 7 9 11 13 15 17 19
1816141210 8642
HDMI TERMINAL(19 pin Type A)
87654321
LAN PORT (RJ-45)
1
TX+
2
TX–
3
RX+
4
- - -
5
- - -
6
RX–
7
- - -
8
- - -
Serial
1
- - -
2
RXD
3
TXD
4
- - -
5
SG
6
- - -
7
- - -
8
- - -
9
- - -
1
Vcc
2
– Data
3
+ Data
4
Ground
1
T.M.D.S. Data2–
9
T.M.D.S. Data1–
17
T.M.D.S. Data0–
2
T.M.D.S. Data2+
10
T.M.D.S. Data1+
18
T.M.D.S. Data0+
3
T.M.D.S. Data2 Shield
11
T.M.D.S. Data1 Shield
19
T.M.D.S. Data0 Shield
4
- - -
12
- - -
20
- - -
5
- - -
13
- - -
21
- - -
6
DDC Clock
14
+5V Power
22
T.M.D.S. Clock Shield
7
DDC Data
15
Ground (for +5V)
23
T.M.D.S. Clock+
8
- - -
16
Hot Plug Detect
24
T.M.D.S. Clock–
1
T.M.D.S. Data 2+ Input
11
Ground (T.M.D.S. Clock)
2
Ground(T.M.D.S. Data 2)
12
T.M.D.S. Clock– Input
3
T.M.D.S. Data 2– Input
13
- - -
4
T.M.D.S. Data 1+ Input
14
- - -
5
Ground (T.M.D.S. Data 1)
15
SCL
6
T.M.D.S. Data 1– Input
16
SDA
7
T.M.D.S. Data 0+ Input
17
Ground (DDC/CEC)
8
Ground (T.M.D.S. Data 0)
18
+5V Power
9
T.M.D.S. Data 0– Input
19
Plug insert detection
10
T.M.D.S. Clock+ Input
1
Red Input
9
+5V Power
2
Green Input
10
Ground (Vert. sync)
3
Blue Input
11
Ground
4
- - -
12
DDC data
5
Ground (Horiz. sync.)
13
Horiz. sync.
6
Ground (Red)
14
Vert. sync.
7
Ground (Green)
15
DDC Clock
8
Ground (Blue)
Appendix
