Sanyo PLC-WTC500L - Page 71

-71-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
300 Closed Caption
0 Caption Mode Caption Mode Select 0: OFF 1: CC1 2: CC2 3: CC3 4: CC4 0-4 0
1 Color Mode Color Mode 0: Follow to transmit Data 1: Fixed 0-1 0
500 Composite (NTSC) Composite / S-Video
1 Disp Dots 0 - 4095 674
2 H Back Porch 0 - 4095 24
3 V Back Porch 0 - 4095 18
4 Disp Line 0 - 4095 454
501 Composite (PAL) Composite / S-Video
1 Disp Dots 0 - 4095 662
2 H Back Porch 0 - 4095 32
3 V Back Porch 0 - 4095 18
4 Disp Line 0 - 4095 542
502 Composite (SECAM) Composite / S-Video
1 Disp Dots 0 - 4095 662
2 H Back Porch 0 - 4095 32
3 V Back Porch 0 - 4095 18
4 Disp Line 0 - 4095 542
510 SCART(480i)
0 Total Dots 0 - 4095 858
1 Disp Dots 0 - 4095 672
2 H Back Porch 0 - 4095 142
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 458
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 20
511 SCART (575i)
0 Total Dots 0 - 4095 864
1 Disp Dots 0 - 4095 656
2 H Back Porch 0 - 4095 148
3 V Back Porch 0 - 4095 56
4 Disp Line 0 - 4095 544
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 20
520 YCbCr (480i)
0 Total Dots 0 - 4095 858
1 Disp Dots 0 - 4095 672
2 H Back Porch 0 - 4095 145
3 V Back Porch 0 - 4095 44
4 Disp Line 0 - 4095 456
5 Clamp 0 - 255 92
6 Clamp Width 0 - 255 20
22 (SUB) H Back Porch 0 - 4095 145
23 (SUB) V Back Porch 0 - 4095 48
24 (SUB) Clamp 0 - 4095 10
25 (SUB) Clamp Witdh 0 - 4095 31
521 YCbCr (575i)
0 Total Dots 0 - 4095 864
1 Disp Dots 0 - 4095 658
2 H Back Porch 0 - 4095 162
3 V Back Porch 0 - 4095 58
4 Disp Line 0 - 4095 542
5 Clamp 0 - 255 98
6 Clamp Width 0 - 255 20
22 (SUB) H Back Porch 0 - 4095 162
23 (SUB) V Back Porch 0 - 4095 58
24 (SUB) Clamp 0 - 4095 10
25 (SUB) Clamp Witdh 0 - 4095 31
522 YCbCr (480P)
0 Total Dots 0 - 4095 1716
1 Disp Dots 0 - 4095 1368
2 H Back Porch 0 - 4095 280
