11
Part Names and Functions Part Names and FunctionsPart Names and Functions
Remote Control
① POWER ON/STAND-BY button
Turn the projector on or off. (pp.18, 19)
④ VIDEO button
Select VIDEO input source. (p.37)
③ COMPUTER 1 button
Select Computer 1 (Analog) or Computer 1 (Digital)
input source. (pp.25, 26)
⑦ MENU button
Open or close the On-Screen Menu. (p.20)
⑩ D.ZOOM ▲▼ buttons
Zoom in and out the images. (pp.24, 36)
⑱ AUTO SET button
Execute the setting of Auto setup (includes Input
search function, Auto PC adj. function and Auto
Keystone function). (pp.22, 24, 28, 46)
⑰ IMAGE button
Select the image level. (pp.24, 31, 40)
⑫ FREEZE button
Freeze the picture. (p.23)
⑮ MUTE button
Mute the sound. (p.23)
⑯ P-TIMER button
Operate the P-timer function. (p.24)
⑬ NO SHOW button
Temporarily turn off the image on the screen. (p.24)
⑲ KEYSTONE button
Correct the keystone distortion. (pp.22, 47)
⑧ Point ▲▼◄► buttons
– Select an item or adjust the value in the On-
Screen Menu. (p.20)
– Pan the image in Digital zoom + mode. (p.36)
⑨ SELECT button
– Execute the selected item. (p.20)
– Expand or compress the image in Digital zoom
mode. (p.36)
⑭ LAMP CONTROL button
Select the lamp mode. (pp.24, 51)
To ensure safe operation, please observe
the following precautions:
– Do not bend, drop or expose the remote
control to moisture or heat.
– For cleaning, use soft dry cloth. Do not
apply benzene, thinner, spray or any
chemical material.
1
2
+
_
⑬
⑰
⑱
⑯
⑭⑫
⑲
⑮
⑧
⑦
⑨
⑩
④
⑤
⑪
⑥
③
①②
② COMPUTER 2 button
Select COMPUTER 2 input source. (pp.25, 38)
⑤ S-VIDEO button
Select S-VIDEO input source. (p.37)
⑥ COMPONENT button
Select COMPONENT input source. (p. 38)
⑪ VOLUME + / – buttons
Adjust the volume level. (p.23)
