KR8-XD220000, KS8-XD260000
For KR8-XD220000
PACKING MATERIALS DIRECTORY
610 349 7440 CARTON CASE-KR8AC
610 351 9722 CUSHION BTM-KR8AC
610 351 9739 CUSHION TOP-KR8AC
645 097 3987 POLY BAG-0550X0600*NC*R8P
ACCESSORIES DIRECTORY
OWNER'S MANUAL
610 349 7679 CD-ROM,OWNERS MANUAL-KR8AC
655 003 3475 SAFETY MANUAL-KG5AC
655 003 6391 SETUP INST-KR8AC
REMOTE CONTROL
645 099 3213 ASSY,REMOCON CXZR
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
!US 645 101 1213 CORD,POWER-1.8MK,US
!EU 645 101 1220 CORD,POWER-1.8MK.EU
!UK 645 101 1237 CORD,POWER-1.8MK,UK
!BRA 645 102 6996 CORD,POWER-2.5MK,BRA
MISCELLANEOUS
610 343 0249 STRAP CAP-KT7AC
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
945 023 4959 CORE,CLAMP
652 003 2767 CORE,CLAMP
CABINET PARTS
C01 610 345 0049 ASSY,ADJ-KR5AC
C02 610 350 7934 CAB BTM LG-KR8AC
C03 610 350 7910 CAB TOP LG SERVICE-KR8AC
C04 610 350 8016 BUTTON CONTROL LG-KR8AC
C05 610 350 8023 COVER LMP LG SERV-KR8AC
C06 610 344 9999 DEC INLAY LED-KR5AC
C07 610 345 0018 DEC INLAY RC-KR5AC
C08 610 350 8030 DEC RING LG-KR8AC
C09 910 325 2477 DEC LEG-PT5EC
C10 610 350 7873 PANEL AV LG-KR8AC
C11 610 350 8054 PANEL NET FRONT LG-KR8AC
C12 610 346 5906 PANEL NET BACK A-KR5AC
(Air filter(back))
C13 610 345 0025 COVER LENS-KR5AC
CHASSIS PARTS
M01 610 345 0087 HOLDER LAMP BASE-KR5AC
M02 610 352 4184 HOLDER POWER(A)-KR5AC
M03 610 343 3721 MTG RELAY OUT-KR5AC
M04 610 343 3738 MTG COND OUT-KR5AC
M05 610 350 4469 MTG DUCT BTM IN LAMP
M06 610 350 4476 MTG DUCT TOP IN LP-KR8AC
M07 610 347 9927 MTG DUCT PANEL-KR5AF
M08 610 345 0223 SPACER FLT FRONT-KR5AC
(Air filter(front))
M09 610 343 3707 OPTICAL TOP-KR5AC
M10 610 343 3714 OPTICAL TOP A-KR5AC
M11 610 343 2588 OPTICAL BASE-KR5AC
SCREWS
S01 411 031 9304 SCR BIN 3X8
S02 411 179 8801 SCR S-TPG BIN 3X10
S03 412 077 8108 SPECIAL SCREW-2.5X6
S04 411 191 6304 SCR BIN 2.5X8
S05 411 192 6709 SCR PAN+SW+W 3X10
S06 411 033 2600 SCR FLT 2X4
OPTICAL PARTS
L01 610 351 7667 ASSY,PNL/PRISM-KR8AC
L03-R 645 101 2135 ASSY,LENS,CONDENSER(R)
L03-G 645 101 2142 ASSY,LENS,CONDENSER(G)
L03-B 645 101 2159 ASSY,LENS,CONDENSER(B)
L04 645 099 6993 LENS,PROJECTION
645 102 2967 LENS,PROJECTION
L05 645 096 4671 LENS,RELAY(OUT)
L06 645 099 0571 LENS,RELAY(IN)
L07 645 099 8447 LENS,INTEGRATOR(IN)
L08 645 099 8454 LENS,INTEGRATOR(OUT)
L09 645 099 8478 LENS,CONDENSER(OUT)
L10 945 086 6372 PRISM(PBS)
L11 645 096 4718 MIRROR(R)
L12 645 099 8492 MIRROR(B)
L13 645 100 5144 DICHROIC MIRROR (B)
L14 645 100 5151 DICHROIC MIRROR (G)
SERVICE TOOLS
610 343 5596 CD-ROM,PJ SVC TOOL V420
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
